라인스캔동축 조명
ILCX Series
![](/skin/img/sub/ilcx_01.jpg)
![](/skin/img/sub/ils_02.jpg)
![](/skin/img/sub/ils_03.jpg)
![](/skin/img/sub/ils_04.jpg)
Specification
균일하게 배열된 고휘도 LED를 사용하고 조명의 일정 세그먼트 마다 조정 기능이 있어 발광 면에 광을 균일하게 조사하여 라인스캔 카메라 조명으로 사용할 수 있습니다.
Application
라인스캔카메라, 필름검사, GLASS검사
![](/skin/img/sub/ILS-200.jpg)
![](/skin/img/sub/ILS-400.jpg)
![](/skin/img/sub/ILS-600.jpg)
![](/skin/img/sub/ILS-800.jpg)
![](/skin/img/sub/ILS-1600D.jpg)
Model | Color | Power | Voltage | LEDs | PDF Download |
---|---|---|---|---|---|
ILCX-100 | SW/RD/GR/BL | 25.2/18.4/25.2/25.2 | 24V | 12 | Click |
ILCX-200 | SW/RD/GR/BL | 50.4/33.6/50.4/50.4 | 24V | 24 | Click |
ILCX-400 | SW/RD/GR/BL | 100.8/67.2/100.8/100.8 | 24V | 48 | Click |
ILCX-600 | SW/RD/GR/BL | 151.2/100.8/151.2/151.2 | 24V | 72 | Click |
ILCX-800 | SW/RD/GR/BL | 200.8/134.4/200.8/200.8 | 24V | 96 | Click |
